SPECS
GENERAL
-
Packaged Quantity1
-
Recommended Usecorporate business, small business
-
Product Form FactorRack-mountable – 1U
-
Built-in Devicesstatus LCD
-
Server Scalability2-way
-
Front Accessible Bays Qty1
-
Hot-Swap Bays Qty8
-
ManufacturerDell, Inc.
PROCESSOR / CHIPSET
-
CPUIntel Xeon E5-2620 / 2 GHz
-
Max Turbo Speed2.5 GHz
-
Number of Cores6-core
-
64-bit ComputingYes
-
Chipset TypeIntel C600
-
Processor Main FeaturesIntel QuickPath Interconnect
-
Processor SocketLGA2011 Socket
CACHE MEMORY
-
Installed Size15 MB
-
Cache Per Processor15 MB
MEMORY
-
Max Supported Size384 GB
-
Form FactorDIMM 240-pin
-
Slots Qty12
-
Empty Slots10
RAM
-
Memory Speed1333 MHz
-
Featureslow-voltage, registered, single rank
-
Configuration Features2 x 4 GB
STORAGE
-
RAID LevelRAID 0, RAID 1, RAID 10, RAID 5, RAID 50, RAID 6, RAID 60
-
Interface TypeSerial Attached SCSI 2
-
Typenone
ENVIRONMENTAL PARAMETERS
-
Humidity Range Operating10 – 80% (non-condensing)
HARD DRIVE
-
Interface TypeSAS 6Gb/s
-
Spindle Speed10000 rpm
STORAGE CONTROLLER
-
Type1 x RAID – integrated
-
Interface TypeSerial ATA-600 / SAS 2.0
-
Storage Controller NameDell PERC H710
-
Buffer Size512 MB
INPUT
-
Typenone
PROCESSOR
-
Installed Qty1
-
Max Supported Qty2
-
Upgradabilityupgradable
CARD READER
-
Typecard reader
MISCELLANEOUS
-
Included AccessoriesReadyRails sliding rails, cable management arm
NETWORKING
-
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
-
Remote Management ProtocolIPMI 2.0
-
Form Factorintegrated
-
Ethernet Ports4 x Gigabit Ethernet
-
Remote Management ControllerIntegrated Dell Remote Access Controller 7 (iDRAC7)
MONITOR
-
Monitor TypeNone.
GRAPHICS CONTROLLER
-
Form Factorintegrated
-
Graphics ProcessorMatrox G200
-
Video Memory16 MB
-
Video InterfacesVGA
DIMENSIONS & WEIGHT
-
Width19 in
-
Depth27.6 in
-
Height1.7 in
MANUFACTURER WARRANTY
-
Type3 years warranty
PRINTER
-
Typenone
ENVIRONMENTAL STANDARDS
-
ENERGY STAR CertifiedYes
EXPANSION / CONNECTIVITY
-
Slots2 (total) / 1 (free) x CPU
12 (total) / 10 (free) x DIMM 240-pin
1 (total) / 1 (free) x PCIe x16 – three-quarter-length, full-height (x16 mode)
1 (total) / 1 (free) x PCIe x16 – half-length, low-profile
PHYSICAL CHARACTERISTICS
-
Form Factorrack-mountable
POWER
-
Typepower supply – hot-plug
-
Power Redundancyyes
-
Power Redundancy Scheme1+1
-
Installed Qty2
-
Max Supported Qty2
-
Min Operating Temperature50 °F
-
Max Operating Temperature95 °F
OPERATING SYSTEM / SOFTWARE
-
OS Provided: Typeno operating system
-
OS ProvidedNo operating system
-
TypeDell OpenManage
GENERAL
-
ManufacturerDell, Inc.
