SPECS
GENERAL
-
Packaged Quantity1
-
Recommended Usecorporate business, small business
-
Product Form FactorRack-mountable – 1U
-
Server Scalability2-way
-
Front Accessible Bays Qty1
-
Hot-Swap Bays Qty4
-
ManufacturerDell, Inc.
PROCESSOR / CHIPSET
-
CPUIntel Xeon E5620 / 2.4 GHz
-
Max Turbo Speed2.66 GHz
-
Number of CoresQuad-Core
-
64-bit ComputingYes
-
Chipset TypeIntel 5500
-
Processor Main FeaturesHyper-Threading Technology, Intel Turbo Boost Technology
-
Processor SocketLGA1366 Socket
CACHE MEMORY
-
Installed SizeL3 cache – 24 MB
-
Cache Per Processor12 MB
RAM
-
Memory Speed1066 MHz
-
Memory Specification CompliancePC3-10600
-
Featuresdual rank, registered
-
Configuration Features4 x 4 GB
-
RAM SupportedPC3-10600 – 128 GB registered – ECC
PC3-10600 – 128 GB unbuffered – ECC
MEMORY
-
Max Supported Size128 GB
-
Form FactorDIMM 240-pin
-
Slots Qty8
-
Empty Slots4
STORAGE
-
RAID LevelRAID 0, RAID 1, RAID 10, RAID 5
-
Interface TypeSerial Attached SCSI
-
Typenone
ENVIRONMENTAL PARAMETERS
-
Humidity Range Operating20 – 80%
HARD DRIVE
-
Interface TypeSAS
-
Spindle Speed10000 rpm
STORAGE CONTROLLER
-
Interface TypeSerial ATA-300 / SAS
-
Storage Controller NameDell PERC S300
PROCESSOR
-
Installed Qty2
-
Max Supported Qty2
-
Upgradabilityupgradable
FLOPPY DRIVE
-
Typenone
NETWORKING
-
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
-
Remote Management ProtocolIPMI 2.0
-
Form Factorintegrated
-
Ethernet Ports2 x Gigabit Ethernet
-
Ethernet Controller(s)Broadcom BCM5716
-
Remote Management ControllerIntegrated Dell Remote Access Controller (iDRAC)
-
FeaturesWake on LAN (WoL)
SOFTWARE
-
Microsoft Office PreloadedIncludes a pre-loaded image of select Microsoft Office 2010 suites. Purchase an Office 2010 Product Key Card or disc to activate preloaded software on this PC.
MONITOR
-
Monitor TypeNone.
GRAPHICS CONTROLLER
-
Form Factorintegrated
-
Graphics ProcessorMatrox MGA G200eW
-
Video Memory8 MB
-
Video InterfacesVGA
DIMENSIONS & WEIGHT
-
Width17.1 in
-
Depth24.7 in
-
Height1.7 in
MANUFACTURER WARRANTY
-
Type3 years warranty
PRINTER
-
Typenone
EXPANSION / CONNECTIVITY
-
Slots2 (total) / 0 (free) x CPU
8 (total) / 4 (free) x DIMM 240-pin
PCIe 2.0 x16 – half-length
PHYSICAL CHARACTERISTICS
-
Form Factorrack-mountable
-
Weight35.05 lbs
POWER
-
Typepower supply
-
Installed Qty1
-
Min Operating Temperature50 °F
-
Max Operating Temperature95 °F
